Sliding Panel Saw STS-16120-CNC I BA9-1020651

Save $7,653.49
$41,137.49
$33,484.00

This CNC table saw lets you store cut programs to ensure accuracy on high-volume, 3-shift schedules. With the sliding table, you need only one operator to cut 10-foot panels. Order this sliding table saw for sale today.

  • 7.5 hp motor with 4 speeds: 3,000, 4,000, 5,000, and 6,000 rpm.
  • Set the RPM by manually moving the belts to different gears.
  • Digital readout (DRO) shows the blade speed to help with repeatability.
  • Comes standard with a 12” blade, but accepts up to a huge 16” blade.
  • Table wood saw turns on a 1” arbor.
  • Runs on 220-volt 3-phase power.
  • 1 hp scoring blade spins at 8,000 rpm to ensure a crisp, clean cut. No need to spend extra time on sanding afterwards.

CNC System:

  • 5.7” touchscreen control panel has a 300 program memory capacity.
  • You can program the cutting width, blade tilt, and blade height of the main saw, as well as the scoring blade height.
  • Save cut settings for a given application or schedule (for example, “Monday Cuts”), so they’re the same each time.
  • Simply choose your desired cut program, and the system will take the table to the right settings. Then, manually push the wood towards the blade.

This CNC sliding table saw is also available in 2 non-CNC versions: STS-14120-DRO (with a digital readout) and STS-14120 (without one).

Fences, Table, and Trunnion:

  • Includes fences for ripping, crosscut, and angled cuts.
  • Servo motor moves the rip fence into place as programmed. No need to read scales. Just dial it in.
  • 2-position rip fence can lift out of the way for crosscutting.
  • Cast iron frame backs the rip fence, keeping it parallel to the saw.
  • Crosscut fence offers 2 DROs (one for the main gantry fence and one for the extension) for repeatability.
  • Angle fence is scaled for precision.
  • Heavy cast steel trunnion has boxed (not dovetailed) ways for extra rigidity.
  • Enormous 15” x 125” sliding table is made of anodized, fully-extruded aluminum, so it’ll stay true and square.
  • Table slides on 4 precision shafts made of polished steel for the smoothest slide possible.
  • Fully welded base made of 12-gauge steel reduces vibrations, maintains alignment, and keeps cuts accurate.
  • Wiper system in the shafts eliminates build-up from sawdust and grease.
  • You can slide a whole sheet of 4’ x 8’ material so easily you’d never think there’s weight on it.
  • Load lock prevents the table from budging when you’re setting down large sheets of wood.
  • 4” main dust port that you can hook up to an extraction system and keep your shop clean.

Safety, Parts, and Warranty:

  • Includes safety blade guards for straight or angled cuts that you can switch in seconds.
  • We typically keep replacement parts in stock for quick shipping.
  • Covered by a 1-year parts warranty.
  • Our team of customer reps—all with hands-on machine experience—are here to provide lifetime technical support by phone.

Recommended for: Industrial production, especially cabinetry manufacturers, lumber liquidators, and railroad yards.
