Automatic Edgebander Pre-milling (0.4mm & 2mm) 21FPM Pre-Milling | CBC.TPM
by Maksiwa
Save $1,095.00
$21,900.00
$20,805.00
💥 5%OFF SAVINGS EVENT— ENDS AUGUST 31!
** FREE Shipping in the USA + FREE 3HP Dust Collector **
The Maksiwa CBC.TPM Automatic Edgebander High Frequency Motor combines precision and efficiency with a compact design, making it ideal for workshops with limited space. It features pre-milling, a gluing unit, a multi-function group for end trimming and top & bottom trimming, glue scraping, buffing, and vertical rounding for versatile performance. Equipped with touchscreen panel, this machine ensures ease of operation and delivers a flawless finish.
Pre-milling in a small footprint
- Edge Tape: 0.4-2 mm
- Panel Thickness: 10-45mm
- 1 Phase 220V 60Hz
- Glue Scraper Unit
- Buffing Unit
- End Trimming HF Motor
- Pre-milling Unit 2 HF Motors
- Glue Pot Capacity 0.5kg | 1lbs Teflon Coated
- Automatic feeding Speed 21 ft/min
- Net Weight 1911 Lbs | 540 kgs
- Compact Design
- Melamine/PVC/ABS/PP
SPECIFICATIONS
- Automatic Feeding Speed: 21 ft/min
- End Trim: Pneumatic
- Panel Thickness (min/max): 13/32” / 1¾”
- Max Pre-Milling Height: 1”
- Edgebanding Thickness: 0.0157” - 0.07”
- Glue Pot Capacity: 1 lbs
- Max Edgebanding Height: 1”
- Minimum Panel Width: 1¾”
- Minimum Panel Length: 4¾”
- Extendable Panel Support Rail Length: 83½”
- Extension Table Max Width: 10”
- Size of Dust Collector Ports: 6”
- Minimum Dust Collection Requirements: 1236 CFM
- Air Pressure Requirements: 14 SCFM @ 87psi
- Edgebanding Coil Support Diameter: 59”
- Recommended Glue Temperature Range: 356°F - 410°F
- Sound Rating: 80 dB
- Conveyor Motor: 1390 RPM 60Hz .66kW
- Top/Bottom Trimmer HFM: 12,000 RPM 200Hz .27kW
- End Trimmer Motor: 12,000 RPM 200Hz .27kW
- Front/Rear Pre-Milling HFM: 9,000 RPM 150Hz .75/.25kW
- Top/Bottom Buffing Motor: 1680 RPM 60Hz .11kW
- Electrical Requirements: 220V Single Phase 60Hz 30Amps
- Machine Dims: 93½” x 40-13/16” x 53”
- Approx Weight: 1,191 lbs
