** FREE SHIPPING **
JET® PTW Series Pallet Trucks has a low profile of less than 3 inches, varying widths of 20 to 27 inches, and different lengths 48 inches. High quality welded steel construction gives the PTW series a capacity of 6,600 pounds. The 200 degree turning radius increases maneuverability and the easy-to-use fingertip controls permit single handed operation. JET PTW Series Pallet Trucks are built to handle heavy lifting.
FEATURES
- Lower material in a controlled decent with either hand or foot control for operator convenience
-
Overload Protection prevents lifting loads past maximum capacity
-
Polyurethane 6-1/4 x 2 inch steer wheels for non marking of floors and quieter rolling
-
Pump designed so that cylinder will not extend beyond maximum height
-
Pumps designed for any industrial environment
- Turning Radius: 210 degrees
- Overload Protection ball valve prevents lifting loads past maximum capacity
- Top-Stroke release valve prevents cylinder extension beyond maximum height
SPECIFICATIONS
| Stock Number | 141172 / 141175 |
|---|---|
| Capacity (Lbs.) | 6600 |
| Fork Width (In.) | 6-1/4 |
| Load Wheel Size (OD x W) (In.) | 2-7/8 x 3-11/16 |
| Lowered Height (In.) | 2.95 |
| Maximum Height (In.) | 7-1/2 |
| Overall Dimensions (L x W x H) (In.) | 63 x 20-1/2 x 48 27X48 |
| Overall Fork Dimensions (L x W) (In.) | 48 x 20-1/2 27X48 |
| Prop 65 | Cancer and Reproductive Harm |
| Steer Wheel Size (In.) | 6-1/4 x 2 |
| Turning Radius (Deg) | 200 |
| Weight (Lbs.) | 140 |
