** FREE SHIPPING **
JET® JTX Series Pallet Trucks have a heavy duty capacity of 8,000 pounds. Each JET JTX Pallet Truck has a low profile of 3-1/4 inches, a width of 27 inches, and a length of 48 inches. The 210 degree turning radius increases maneuverability and the easy-to-use fingertip controls permit single handed operation. JET JTX Series Pallet Trucks are built to handle heavy lifting
FEATURES
- Capacity: 8,000 lb.
- Turning Radius: 210 degrees
- Overload Protection ball valve prevents lifting loads past maximum capacity
- Top-Stroke release valve prevents cylinder extension beyond maximum height
- Chrome-plated pump piston and ram provide corrosion resistance in any industrial environment
- One-piece cast iron pump has a built-in valve that lowers the material in a controlled decent
- Poly over aluminum 8 x 2 inch steer wheels ensure contact with uneven floors
- Steer wheels feature double sealed lubricated bearings
SPECIFICATIONS
- Capacity (Lbs.) 8,000
- Turning Radius (Deg) 210
- Overall Fork Dimensions (L x W) (In.) 48 x 27
- Fork Width (In.) 6-1/4
- Lowered Height (In.) 3-1/4
- Maximum Height (In.) 6-1/4
- Number of Strokes to Reach Maximum Height 13 to 14
- Force Required to Pump @ Maximum Load (Lbs) 222.5
- Steer Wheel Size (In.) 8 x 2
- Load Wheel Size (OD x W) (In.) 3-1/4 x 3-1/2
- Force Required to Move Maximum Load (Lbs) 126
- Overall Dimensions (L x W x H) (In.) 63-1/2 x 27 x 49-1/4
- Weight (Lbs) 239
- W1 Fork Width (In) 6-1/4
- W2 Overall Width (In) 27
- L1 Fork Length (In) 48
- L2 Overall Length (In) 63-1/2
- H1 Max. Raised Height (In) 6-1/4
- H2 Min. Raised Height (In) 3-1/4
- A Steer Wheel Dimensions (In) 8 x 2
- B Fork Wheel Dimensions (In) 3-1/4 x 3-1/2
- C Overall Height (In) 49-1/4
