12″ Contractor Duty Radial Arm Saw, 3HP Single-Phase OR 3PH | 3512

12″ Contractor Duty Radial Arm Saw, 3HP Single-Phase OR 3PH | 3512

Name: 12″ Contractor Duty Radial Arm Saw, 3HP Single-Phase OR 3PH | 3512
Brand: Original Saw
SKU: 3512-01-208
Price: 6953.11 USD
Availability: InStock

by Original Saw

$6,953.11

Motor phase

Voltage Options

Quantity

** FREE SHIPPING **

12″ Contractor Duty Radial Arm Saws are industrially-rated. This model has the versatility cut the following:

crosscut
bevel cut
miter cut
compound miter
cut dado cutting operation
Crosscut, Bevel, Miter, Compound Miter, Dado, and Rip (with Rip Kit Add On)

Cut 3″ deep with a 24″ crosscut with a 12″ Radial Arm Saw. Most important, it is ideal for cutting 24″ wide panels for squaring shelving, doors, and other similar applications.

Original Saw Company takes pride in manufacturing American-made products.

Order the Contractor Series Radial Arm Saw with a single or three-phase motor. Original Saw Company makes Radial Arm Saws from cast iron and heavy gauge, formed steel. Additionally, a durable, powder-coated finish provides years of protection.

All Contractor Duty Saws come standard with both an E-Stop and an oversized MDF table. With a TEFC (totally enclosed fan-cooled) motor and internal automatic brake, this radial arm saw has the best cut quality in its class.

Recent Updates to 12″ Radial Arm Saws Include the Following:

High-density polyethylene lower guards provide full coverage.
New yoke assemblies allow for precise bevel clamping on angles. Additionally, the yoke swivels to rip with RIP KIT INCLUDED.
The elevating crank and the yoke pull grip have re-engineered handle grips for ease of use.
Lastly, an E-Stop is a standard feature on all Radial Arm Saws. An E-Stop is a safety mechanism to shut off machinery in an emergency. This switch halts the operation of the Radial Arm Saw. It shuts off all potential hazards outside of the saw’s power enclosure.

Ripping with a Radial Arm Saw

Radial Arm Saws can be the centerpiece of the workshop.

Make a rip cut by cutting lengthwise or parallel to the grain. The motor swivels parallel to the fence when Original Saw Company’s Rip Kit is ordered and installed on a wood-cutting Radial Arm Saw. Wider boards can be cut into narrower pieces when rip-cutting. Original Saw Company’s Rip Kit includes an anti-kickback assembly for added safety precautions.

FEATURES

24” crosscut
3” depth of cut
3 HP
MDF table top
E-Stop
Carriage rides on 4 tight-tolerance, horizontally mounted convex bearings
Arbor nut and precision ground arbor collars
Wrench kit (includes Allen arbor wrench and flat arbor wrench)
Automatic blade braking system
Standard work table height 32”
HDPE (high-density polyethylene) lower blade guard that provides full coverage
Made in USA Manufacturing of Radial Arm Saws happens after the customer orders. Machines are considered custom and are made voltage specific.
Because some cutting applications are custom and specific, our team may contact you about your purchase. It is our priority to build a saw that fits our customers’ needs.
Radial Arm Saws are assembled and tested in our facility. After being test run, the saw is packaged and placed on a skid. The legs are attached to the skid. This makes setup and installation easy.
Shroud - Dust Collection Kit included

SPECIFICATIONS

Weight	440 lbs
Dimensions	48 × 40 × 48 in
Motor	3 HP 1 phase TEFC (totally enclosed fan cooled) motor, 3 HP 3 phase TEFC (totally enclosed fan cooled) motor
Product Length (Inches)	40
Product Width (Inches)	36
Product Height (Inches)	53
Cuttable Material	Plastic, Wood
Max Crosscut	24" wide
Max Depth Cut	3" deep
Can do the following cuts	Bevel, Compound Miter, Crosscut, Dado, Miter Rip (with Rip Kit Add On)
Capable of Rip Cuts	Yes
Recommended Usage	Used up to 6 hours per day
Voltage Options	208V, 230V, 460V, 575V
Phases of Voltage Available	Single Phase or Three Phase
Pneumatic Clamping Ability?	No
Powered Feed Option?	No
