** FREE SHIPPING **
FEATURES
- Heavy-duty design with powerful driving motor offers high efficiency in production environments
- Belt oscillation by gear reducer
- Front, Back and Side tables are adjustable in height by handwheel and can be tilted for bevel sanding operations
- Quick belt change with adjustable belt tension
- Built of heavy welded plate steel for rugged base construction and vibration free sanding.
- CSA approved electrics.
SPECIFICATIONS
- Sanding motor: 10 HP
- Oscillating stroke: 0.472”
- Sanding belt size: 12” x 166”
- Sanding belt speed: 970 RPM
- Table: front: 10.43” x 60.9”
- Table: rear: 10.43” x 60.9”
- Table: side: 13.8” x 17.7”
- Front table tilt: 45°
- Side table tilt: 45°
- Machine size: 90.5” x 30.7” x 50.79”
- Packing measurement: 94.5” x 34.6” x 59”
- Machine weight: 1155 lbs
- Shipping weight: 1430 lbs.
-
Electrical requirement: 230/3/60 = 28 amps / 575/3/60 = 11 amps
